Compressor Wheel Inducer: 63.5mm
Compressor Wheel Exducer: 88mm
Compressor Wheel Trim: 52
Turbine Wheel Inducer: 72.5mm
Turbine Wheel Exducer: 66.5mm
Turbin Wheel Trim: 84
Turbine Housing: .90
Turbine Vanes: Altered for Higher Flow
- Garrett patented Advanced Variable Nozzle Turbine (AVNT) design for increased compressor flow and boost response.
- Nine movable vanes that significantly increase turbine efficiency and improve engine performance from idle launch through peak torque.
- Patented integral electro-hydraulic actuation and proportional solenoid for infinite variable control.
- Larger compressor wheel over stock increases maximum power range while keeping turbo speeds down for the same power output
- Supports up to an additional 175 HP over stock with no sacrifice in drivability
